Feed Azure DevOps Data into FineReport

The CData JDBC Driver for Azure DevOps fully implements the JDBC standard and can provide Azure DevOps data connectivity to a wide variety of BI, reporting, and ETL tools and custom applications. In this article, we explain how to set Azure DevOps data as JDBC data source in FineReport and view Azure DevOps data as a table in the Report Designer.

Set Up a JDBC Data Source of Azure DevOps Data

Follow the instruction below to set Azure DevOps data as a FineReport database connection.

1. Copy the cdata.jdbc.azuredevops.jar file from the lib folder in the CData JDBC Driver for Azure DevOps installation directory to the lib folder of the FineReport installation directory. You will need to copy the cdata.jdbc.azuredevops.lic file as well.
2. From the Server tab, select Define Data Connection, click to add a new connection, and click JDBC.

Next we will set up the data connection definition in the window.

1. Database: Others
2. JDBC Driver: cdata.jdbc.azuredevops.AzureDevOpsDriver
3. URL: A standard JDBC connection string using semicolon-separated connection properties. You can connect to your Azure DevOps account by providing the Organization and PersonalAccessToken.

   Obtaining a Personal Access Token

   A PersonalAccessToken is necessary for account authentication.

   To generate one, log in to your Azure DevOps Organization account and navigate to Profile -> Personal Access Tokens -> New Token. The generated token will be displayed.

   If you wish to authenticate to Azure DevOps using OAuth refer to the online Help documentation for an authentication guide.

   Built-in Connection String Designer

   For assistance in constructing the JDBC URL, use the connection string designer built into the Azure DevOps JDBC Driver. Either double-click the JAR file or execute the jar file from the command-line.

   java -jar cdata.jdbc.azuredevops.jar

   Fill in the connection properties and copy the connection string to the clipboard.

   When you configure the JDBC URL, you may also want to set the Max Rows connection property. This will limit the number of rows returned, which is especially helpful for improving performance when designing reports and visualizations.

   A typical JDBC URL is below:

   jdbc:azuredevops:AuthScheme=Basic;Organization=MyAzureDevOpsOrganization;ProjectId=MyProjectId;PersonalAccessToken=MyPAT;
4. Click Connection pool attributes and set Test before getting connections to No.

Click Test connection to ensure you have configured the connection properly. With the connection to Azure DevOps set up, you can use it as FineReport data source.

Select Azure DevOps Data in the Report Designer.

1. Click to add a new template data set and select DB query to open the database query window.
2. Choose the JDBC connection that you created from the dropdown list.
3. The Azure DevOps entities will appear as tables on the left pane.
4. Write a SELECT statement for the Azure DevOps data tables and columns that you want to load.
5. Click preview and data is shown as table.

With these simple steps, Azure DevOps can be used as a JDBC data source in FineReport.
